Brand new aftermarket voltage regulator rectifier

  • Direct replacement to your original unit.
  • Plug-and-play direct fit easy installation.
  • No assembly required
  • Higher grade of electric components.
  • The quality exceeds the OEM equipment
  • All products shipped are tested

All item pictures are accurate if in doubt do not hesitate and compare our item to your original part.

Specifications:

Dimensions:

  • W idth: 70 mm
  • Length: 82 mm
  • Height: 29 mm
  • Fixation holes center to center: 88 mm

Other specifications:

  • Number of pins: 4
  • Minimum Charging Voltage: 14.5V +/- 0.5V
  • Maximum Charging Current: 50A/500W
  • Open Circuit Voltage: <15V
  • Operation Temperature: -20° to 85°

Note: Battery condition is extremely important. No voltage regulator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt have the battery load tested or replaced.

(WPS-RMS020101609)

SKU WPS-RMS020101609
Brand Whites
Shipping Weight 0.5000kg
Shipping Width 0.400m
Shipping Height 0.300m
Shipping Length 0.500m
